MX2204 HOBO TidbiT MX Bluetooth Temperature Data Logger 1500m

MX2204

Onset

New

Grupo 1

icon-app-store.png   en_app_rgb_wo_60.png

The HOBO MX2204 TidbiT water temperature logger leverages the power of Bluetooth Low Energy (BLE) to deliver high-accuracy temperature measurements straight to your iOS or Android mobile device. Designed for durability, this rugged waterproof logger is ideal for long-term deployments in streams, lakes, and oceans. Data collection in the field has never been easier!

BUYING IN BULK, OR JUST WANT SOME USEFUL ADVICE?
Call +34 916292106 or complete our "More info about this Product" form

165,00 €

Add to wishlist

Number of Channels 1 channel (temperature)
ADC Bits 16 bit
Precision ±0.2°C
With Display No
IP Classification IP67
Communications Bluetooth BLE
Battery Life 2 years
Memory Capacity 96,000 measurements

Highlighted Features

  • Convenient wireless setup and download via Bluetooth Low Energy (BLE)
  • Large memory stores 98,000 measurements
  • Waterproof to 1500 meters (5000 feet)
  • Waterproof boot protects the logger during deployment
  • LED alarm notifies you when temperature exceeds set threshold
  • Water detection feature conserves battery life
  • Works with Onset’s free HOBOmobile app
  • ±0.2°C (±0.36°F) accuracy

In what environment does this data logger operate?

This data logger operates in indoor, outdoor and underwater environments.

What measurements does this data logger support?

The MX2204 data logger supports the following measurements: Temperature and Water Temp

Temperature Sensor (MX2203 and MX2204)

Range

MX2203: -20° to 70°C (-4° to 158°F) in air; -20° to 50°C (-4° to 122°F) in water

MX2204: -20° to 70°C (-4° to 158°F) in air; -20° to 50°C (-4° to 122°F) in water, maximum sustained temperature in water 30°C (86°F)

Accuracy

±0.25°C from -20° to 0°C (±.45°F from -4° to 32°F)

±0.2°C from 0° to 70°C (±0.36°F from 32° to 158°F)

Resolution

0.01°C (0.018°F)

Drift

<0.1°C (0.18°F) per year

Response Time

MX2203: 17 minutes typical to 90% in air moving 1 m/s, unmounted;

7 minutes typical to 90% in stirred water, unmounted

MX2204: 15 minutes typical to 90% in air moving 1 m/s, unmounted;

4 minutes typical to 90% in stirred water, unmounted



Logger

Radio Power

1 mW (0 dBm)

Transmission Range

Approximately 30.5 m (100 ft) line-of-sight

Wireless Data Standard

Bluetooth Smart (Bluetooth Low Energy, Bluetooth 4.0)

Logger Operating Range

-20° to 70°C (-4° to 158°F)

Logging Rate

1 second to 18 hours

Buoyancy (Fresh Water)

MX2203: 3.1 g (0.11 oz) negative

MX2204: 7.6 g (0.27 oz) negative

Waterproof

MX2203: To 122 m (400 ft)

MX2204: To 1,524 m (5,000 ft)

Water Detection

Water conductivity level of 100 µS/cm or greater necessary for reliable detection of water. Deionized water or water below 100 µS/cm may not be detected.

The water conductivity circuit may not reliably detect water that has frozen around the electrodes, i.e. below 0°C (32°F).

Memory

96,000 measurements

Battery

CR2477 3V lithium, user replaceable in MX2303, non-replaceable in MX2304

Battery Life

3 years, typical at 25°C (77°F) with logging interval of 1 minute and Bluetooth Always Off disabled in software.

5 years, typical at 25°C (77°F) with logging interval of 1 minute and Bluetooth Always Off or Bluetooth Off Water Detect enabled in software.

Faster logging intervals and statistics sampling intervals, burst logging, remaining connected with the app, excessive downloads, and paging may impact battery life.

To ensure proper battery installation, see Battery Information for detailed instructions on replacing the battery in the MX2203 logger.

Time Accuracy

± 1 minute per month at 25°C (77°F)

Full Memory Dowload

Approximately 45 seconds; may take longer the farther the device is from the logger

Wetted Materials

MX2303: Polypropylene case, EPDM O-ring, stainless steel screws, Santoprene® (TPE) boot

MX2304: Epoxy case, Santoprene (TPE) boot

Dimensions

MX2203: 4.45 x 7.32 x 3.58 cm (1.75 x 2.88 x 1.41 inches)

MX2204: 4.06 x 6.99 x 3.51 cm (1.6 x 2.75 x 1.38 inches)

Weight

MX2203: 36.2 g (1.28 oz)

MX2204: 32.8 g (1.16 oz)

The CE Marking identifies this product as complying with all relevant directives in the European Union (EU). This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
