SMR46 BOD (Biological Oxygen Demand) Analyzer

SMR46

Aquas Inc.

New

The Biochemical Oxygen Demand (BOD) analyzer connects directly via the RS485 communication interface, providing simple, reliable and cost-effective process data with remote monitoring, calibration, configuration and diagnostic capabilities.

Add to wishlist

Housed in a rugged IP68-protected housing, with a Kevlar-reinforced cable with a tensile strength of 1500 N and digital data transmission of up to 1.2 km, the transmitter is ideal for the water and wastewater industry.

Advantages:

All-in-One Compact Housing, Built-in Transmitter and Sensors

Robust IP68 Water Submersible Protection, Directly Installed in the Field, No Cabinet Required

Plug & Play, On-line Realtime Measurement

Ultra Low Power Consumption, Ideal for Outdoor Applications

1500 N Tensile Strength Kevlar Reinforced Cable

Built-in Temperature, Humidity Monitoring and LED Failure Self Diagnosis Function

Advanced Intelligent Algorithm and Signal Processing Technology to Eliminate Noise

Surge Protection for Power and RS485 Communication

RS485 Digital Communication, Minimize Cabling and Engineering Cost

Standard Modbus RTU Protocol, Direct Connected with PLC, HMI

Sapphire Glass Windows to Prevent Scratch

Innovative Nano Coating to Remain Window Clean

Auto Cleaning Wiper, Minimal Maintenance

Built-in Reference Light Measurement to Compensate Aging of the Light and Bio Film Influence

Turbidity or Suspended Solids and Temperature Measurement and Compensation

Onboard Memory to Easily Calibrate and Configure Sensor at Lab and Distribute to Various Fields

AQCFG Software Tool for Data Monitoring, Calibration, Configuration and Diagnosis

IECEx/ATEX Ex ia IIB T4/T5 Ga Explosive Proof Certification
