SD-VOLT-xx HOBO Self-Describing DC Voltage Input Cable

Reference

Manufacturer: Onset

Condition: New

- Self-Describing technology for quick, easy setup
- Locking jack to ensure cable is connected and stays connected
- Measurement range:
      - 0 to 2.5 V (w / SD-VOLT-2.5)
      - 0 to 5 V (w / SD-VOLT-05)
      - 0 to 10 V (w / SD-VOLT-10)
      - 0 to 24 V (w / SD-VOLT-24)
- Accuracy:
      - ± 0.1 mV ± 0.1% of reading (w / SD-VOLT-2.5)
      - ± 0.2 mV ± 0.3% of reading (w / SD-VOLT-05)
      - ± 0.4 mV ± 0.3% of reading (w / SD-VOLT-10)
      - ± 1.0 mV ± 0.3% of reading (w / SD-VOLT-24)
- Cable length: 1.8 m (6 ft)

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

39,00 €

tax excl.

Quantity

Voltage Range

Add to wishlist

OVERVIEW
SPECIFICATIONS
Data sheet
Download

The Sensor measures:	Vdc & mVdc
Cable Length:	1.8 m

SD-VOLT-xx Data Sheet Download (66.16k)

SD-VOLT-xx Manual Download (448.8k)

For use with HOBO MX1104 and MX1105 multi-channel data loggers.
This DC voltage input cable allows integrated strain relief to keep it connected to the logger.
It features Self-Describing technology to automatically communicate its configuration information to the data logger.

In what environment does this sensor operate?
This sensor operates in an indoor environment.

What measurements does this sensor support?
The SD-VOLT-xx sensor supports the following measurement: DC Voltage

	SD-VOLT-2.5	SD-VOLT-05	SD-VOLT-10	SD-VOLT-24
Maximum Input	0 to 2.5 VDC	0 to 5 VDC	0 to 10 VDC	0 to 24 VDC
Accuracy	±0.1 mV ±0.1% of reading	±0.2 mV ±0.3% of reading	±0.4 mV ±0.3% of reading	±1.0 mV ±0.3% of reading
Impedance	> 1 MΩ	20 KΩ	20 KΩ	48 KΩ
Resolution	0.002% of full scale
Cable Length	1.83 m (6 ft)
