P4151 Temperature Transducer Pt1000 0°C to +35°C / 4 to 20 mA

P4151

Comet System

New

Volume discounts

Quantity Price
You Save
%
1+ 40,00 € 0%
5+ 39,20 € 2%
10+ 38,40 € 4%
15+ 37,65 € 5.875%

Add to wishlist

Temperature transducer for Pt1000 sensors. Outdoor, indoor use.

For external Pt1000 temperature probe.

Included in delivery:

  • Traceable calibration certificate
  • Quick start manual
Technical parametersValue
Output 4-20mA
Measured Value Temperature
Construction Type For External Temperature Probe Pt1000
Design Industrial
Temperature Measuring Range 0 to +35°C
Relay Output No
Two-State Input No
Lcd Display No
PoE No
Accuracy of temperature output ±0.2°C
Temperature range of 4-20mA output 0 to +35°C
Temperature operating range -30 to +80°C
Current output - two-wire connection 4-20mA
Break of sensor >24mA
Short circuit of sensor <3.5mA
IP protection IP65
Power 9-30Vdc, typically 24V
Dimensions 88.5 x 117 x 39.5 mm (W x H x D)
Weight approximately 125g
Warranty 2 years
Pt1000TG8/0, temperature probe, cable 1 m
code: SN104
Pt1000TG8/0, temperature probe, cable 1 m
Pt1000TG8/0, temperature probe, cable 2 m
code: SN105
Pt1000TG8/0, temperature probe, cable 2 m
Pt1000TG8/0, temperature probe, cable 5 m
code: SN108
Pt1000TG8/0, temperature probe, cable 5 m
Pt1000TG8/0, temperature probe, cable 10 m
code: SN113
Pt1000TG8/0, temperature probe, cable 10 m
Pt1000TG7/0, temperature probe, cable 1 m
code: SN164
Pt1000TG7/0, temperature probe, cable 1 m
Pt1000TG7/0, temperature probe, cable 2 m
code: SN165
Pt1000TG7/0, temperature probe, cable 2 m
Pt1000TG7/0, temperature probe, cable 5 m
code: SN166
Pt1000TG7/0, temperature probe, cable 5 m
Pt1000TG7/0, temperature probe, cable 10 m
code: SN167
Pt1000TG7/0, temperature probe, cable 10 m
2301-220/0, temperature probe, cable 1 m
code: SN168
2301-220/0, temperature probe, cable 1 m
2021-150/0, temperature probe, cable 1 m
code: SN169
2021-150/0, temperature probe, cable 1 m
PTS350A-2/0, temperature probe, cable 2 m
code: SN170
PTS350A-2/0, temperature probe, cable 2 m
2034-220/0, temperature probe, cable 1 m
code: SN175
2034-220/0, temperature probe, cable 1 m
2061-200/0, temperature probe, cable 1 m
code: SN178
2061-200/0, temperature probe, cable 1 m
2061-200/0, temperature probe, cable 2 m
code: SN179
2061-200/0, temperature probe, cable 2 m
2061-200/0, temperature probe, cable 5 m
code: SN180
2061-200/0, temperature probe, cable 5 m
2061-200/0, temperature probe, cable 10 m
code: SN181
2061-200/0, temperature probe, cable 10 m
PTS350A-5/0, temperature probe, cable 5 m
code: SN182
PTS350A-5/0, temperature probe, cable 5 m
PTS350A-10/0, temperature probe, cable 10 m
code: SN183
PTS350A-10/0, temperature probe, cable 10 m
Pt1000TGL40/0, temperature probe, cable 1 m
code: SN185
Pt1000TGL40/0, temperature probe, cable 1 m
Pt1000TGL40/0, temperature probe, cable 2 m
code: SN186
Pt1000TGL40/0, temperature probe, cable 2 m
Pt1000TGL40/0, temperature probe, cable 5 m
code: SN187
Pt1000TGL40/0, temperature probe, cable 5 m
Pt1000TGL40/0, temperature probe, cable 10 m
code: SN188
Pt1000TGL40/0, temperature probe, cable 10 m
Pt1000TR160/0, temperature probe, cable 1 m
code: SN199
Pt1000TR160/0, temperature probe, cable 1 m
Pt1000TR160/0, temperature probe, cable 2 m
code: SN200
Pt1000TR160/0, temperature probe, cable 2 m
Pt1000TR160/0, temperature probe, cable 5 m
code: SN201
Pt1000TR160/0, temperature probe, cable 5 m
Pt1000TR160/0, temperature probe, cable 10 m
code: SN202
Pt1000TR160/0, temperature probe, cable 10 m
Pt1000TR160/0, temperature probe, cable 15 m
code: SN203
Pt1000TR160/0, temperature probe, cable 15 m
Pt1000TR160/0, temperature probe, cable 20 m
code: SN204
Pt1000TR160/0, temperature probe, cable 20 m
PTS380K/0 temperature sensor with a stainless steel connection head and connector
code: SN205
PTS380K/0 temperature sensor with a stainless steel connection head and connector
2091-200/0, Stick-in probe, cable 1 m
code: SN210
2091-200/0, Stick-in probe, cable 1 m
2091-200/0, Stick-in probe, cable 2 m
code: SN211
2091-200/0, Stick-in probe, cable 2 m
2091-200/0, Stick-in probe, cable 5 m
code: SN212
2091-200/0, Stick-in probe, cable 5 m
2091-200/0, Stick-in probe, cable 10 m
code: SN213
2091-200/0, Stick-in probe, cable 10 m
2071-030/0, special probe with CINCH connector
code: SN214
2071-030/0, special probe with CINCH connector
