TC6-T  T type Thermocouple (-200°C to 180°C) View larger

TC6-T T type Thermocouple (-200°C to 180°C)

TC6-T

Onset

New

At AlphaOmega-Electronics you will find the best range of Thermocouple sensor and at the most competitive prices.

32,00 €

tax excl.

Add to wishlist

The Sensor measures: Temperature
Output Signal: mV
Cable Length: 1.8 m

The Type T 6 ft Beaded Thermocouple probe includes 1.8m (6') of insulated 30-AWG wire wound on an integrated spool caddy /subminiature connector. Color-coded for type T (blue) thermocouples according to the ANSI standard, this probe is teflon-insulated and responsive over a range of -200°C to -65°C (-330°F to -85°F) with an initial accuracy of ±1.0°C (±1.8°F) for probe only over the range of -65°C to 130°C (-85°F to 270°F). Overall accuracy varies with attached logger. Initial Accuracy: ±0.75%.

Range: -200°C to -65°C (-330°F to -85°F)
Initial Accuracy: ±1.5%***
Range: -65°C to 130°C (-85°F to 270°F)
Initial Accuracy: ±1.0°C (±1.8°F)
Range: 130°C to 180°C (270°F to 356°F)
Initial Accuracy: ±0.75%***
Insulation: Teflon

Notes: Teflon insulation is rated up to 200°C (400°F) continuous, and +250°C (+482°F) for 24 hours.

*** Percentage is of degrees above or below 0°C (32°F)
