Although carbon dioxide is not visible, a higher CO2 content in the room leads to fatigue and decreased mental concentration.
APPLICATIONS - CO2 monitoring at:
building HVAC management
meeting rooms, hospitals, cinemas, theatres
The CO2 - carbon dioxide level is recently regarded as an important parameter that substantially determines the quality of the interior climate. Especially in buildings where many people gather, such schools, meeting rooms, hospitals, cinemas, theatres and care centres. With the help of CO2 sensor engineers, technical advisors, environmental experts and health specialists can optimize the ventilation for creation of a healthy interior climate.
Method of CO2 monitor multipoint calibration leads to an excellent accuracy measurements of CO2 in the entire ofoperating temperature range. With this sensor is the device able to meet the demanding requirements for outdoor use.The measurement principle is based on the NDIR principle with dual wavelength, which automatically compensates foraging of the sensor. The sensor is resistant against the pollution and provides maintenance-free operation and excellent long-term stability. Transmitter contains a microprocessor based control circuitry in a durable plastic case with connection terminals.
The CO2 concentration sensor is built inside the case.
Measured Value CO2
Construction Type Ambient Air
Green LED lights - CO2 concentration 0 to 1000 ppm
Yellow LED lights - CO2 concentration 1001 to 1400ppm
Red LED lights - CO2 concentration 1401ppm and more
Accuracy of CO2 concentration measurement ±(50ppm +2% from reading) at 25°C and 1013hPa
Temperature operating range -30 to +60°C
IP protection IP30
Dimensions 88.5 x 73 x 39.5 mm (W x H x D)
Weight approximately 145g
Warranty 2 years
