Tempmate-M1 Temperature Data Logger with Display & PDF analysis




Volume discounts

Quantity Price
You Save
1+ 48,00 € 0%
5+ 43,20 € 10%
10+ 38,40 € 20%
25+ 33,60 € 30%
50+ 28,80 € 40%
100+ 24,00 € 50%

48,00 €

Add to wishlist

Environment of Use Indoor/Outdoor
Type of Logger Portable
Measured Parameters Temperature
Number of Channels 1 Temp.: –30°C to +70°C (–40°C to +90°C with ext. Sensor)
ADC Bits 10 bit
Precision ±0.5°C
Resolution 0.1°C
With Display Multifunction LCD
IP Classification IP67
Communications USB
Battery Life CR2032 / replaceable by customer
Memory Capacity 32000

Tempmate-M1, our best data loggers for temperature recording with internal or external temperature sensor, Mulifunktions display and automatic PDF report generation.

Economic multi-use GDP compliant temperature data logger with automated PDF analysis for smart logistics.

• Compact size and easy handling
• Integrated USB interface
• Pre-configured and ready to start directly without software and PC
• Multiple adjustable alarm limits (3 x high, 2 x Low)
• Flag Function
• Multiple recording with temporary PDF
• Automatic PDF report generation
• Multifunction LCD
• MKT value is calculated automatically
• Compatible with TempBase management software and cloud
• Readjustment of the sensor at any time through the possible software
• EN12830 compliant and GDP
• Battery replaceable by customer
• Calibration certificate as a PDF on the logger saved
• IP67 protection class

Temperature sensor: NTC internal and external optional

Measurement range: -30 ° C to +70 ° C.

Accuracy: ± 0.5 ° C (at -20 ° C to + 40 ° C)

Resolution: 0.1 ° C

Response time T90: 11 min.

Data storage: 32,000 values

Display: Multifunction LCD

Start setting: manually by pressing a button or automatically programmed start time

Recording time: By customer freely programmable / up to 12 months

Measurement interval: 10 Sec. up to 24 hours.

Alarm settings: adjustable up to 5 alarm limits

Alarm type: Single alarm or cumulative

Battery: CR2032 / replaceable by customer

Dimensions: 80mm x 34mm x 14mm (L x W x D)

Weight: 30 g

Protection class: IP67

System requirements: PDF Reader

Certification: 12830, calibration certificate, CE, RoHS

Software: TempBase Lite 1.0 software / free download

Interface to PC: integrated USB port

Automatic PDF Reporting: yes
