3042 Phosphate Analyzer

Waltron’s 3040 series colorimetric analyzers provide exceptional results for online measuring of silica, phosphate and other parameters.

Small size and compact layout make the 3040 series an excellent choice for a variety of applications and environments. Waltron’s 3040 series colorimetric analyzers have been completely redesigned to offer unique and simplified configurations compared to previous models.

Sensor Classification
Colormetric with glass flowcell and LED source

Application
Boiler water, and cooling water

Digital Outputs
Communication interface via RS-232 & RS-485 using MODBUS RTU protocol

Power Supply
110-220Vac, 50-60 Hz 80 VA

Humidity
Up to 90% not condensable

Ambient Temperature Range
10-45º C analyzer (50-113º F)

Range
0 – 5ppm, 0 – 15ppm; 0 – 150ppm*, 0 – 750ppm*
*By Auto Dilution

Accuracy
+/– 2% of full scale

Unit Dimensions
Height=23.6”(60 cm), Width=15”(38 cm), Depth=8.3”(21 cm)

Atmospheric Pressure Range
No Limits

Positioning and installation details
Wall mounting or with bench support, panel mounting (optional)

Response Time (approximate)
<10min, batch process, programmable cycle>

Alarms
2 or 4 configurable alarm relays

Reproducibility
+/– 2% of reading

Degree of Protection (approximate)
IP55 (NEMA 4): Wet section, IP65 (NEMA 4x): Electronics

Required Maintenance
Once a month replenish reagents, Quarterly replace tubing

Reagent Consumption (approximate)
1 or 2 reagents (depending on range), 2L each per month

Materials in Contact with Sample
Glass, Silicone, Plexiglass, Stainless Steel AISI 316

Certification (on request):
Meets low voltage and low electromagnetic compatibility directives

Sample Conditioning Requirements
Filtering between 10 and 60 micron, depending on the matrix, needed only to avoid clogging.

Weight
17 kg (37.5 lbs.)

SAMPLE DELIVERY OPERATING CONDITIONS

Temperature Range
5-55º C (41-131º F)

Inlet Sample
100–500 ml/min, atmospheric, flexible tubing O.D. 1/4

Outlet Sample
Atmospheric, waste tubing O.D. 3/8

Turbidity
Not applicable, sample blank correction

Color
Not applicable, sample blank correction

PH
3-12

SIGNAL OUTPUTS

Analog Outputs:
4-20mA (galvanic isolator module available as option) or 0-5V

Serial I/O for Signals:
Serial data output RS232 standard, RS485 available as option

OPERATIONAL CALIBRATION

Frequency/Intervals
Recommended: 7 days

Single/Multi Point
Multi-Point: zero and mid range

Matrix Corrections
Yes, sample blank correction

Manual/Automatic
Both
