3042 Analizador de Fosfato

Los analizadores colorimétricos de la serie 3040 de Waltron proporcionan resultados excepcionales para la medición en línea de sílice, fosfato y otros parámetros. El diseño pequeño y compacto hace de la serie 3040 una excelente opción para una variedad de aplicaciones y entornos. Los analizadores colorimétricos de la serie 3040 de Waltron han sido completamente rediseñados para ofrecer configuraciones únicas y simplificadas en comparación con los modelos anteriores.

Sensor Classification
Colormetric with glass flowcell and LED source

Application
Boiler water, and cooling water

Digital Outputs
Communication interface via RS-232 & RS-485 using MODBUS RTU protocol

Power Supply
110-220Vac, 50-60 Hz 80 VA

Humidity
Up to 90% not condensable

Ambient Temperature Range
10-45º C analyzer (50-113º F)

Range
0 – 5ppm, 0 – 15ppm; 0 – 150ppm*, 0 – 750ppm*
*By Auto Dilution

Accuracy
+/– 2% of full scale

Unit Dimensions
Height=23.6”(60 cm), Width=15”(38 cm), Depth=8.3”(21 cm)

Atmospheric Pressure Range
No Limits

Positioning and installation details
Wall mounting or with bench support, panel mounting (optional)

Response Time (approximate)
<10min, batch process, programmable cycle>

Alarms
2 or 4 configurable alarm relays

Reproducibility
+/– 2% of reading

Degree of Protection (approximate)
IP55 (NEMA 4): Wet section, IP65 (NEMA 4x): Electronics

Required Maintenance
Once a month replenish reagents, Quarterly replace tubing

Reagent Consumption (approximate)
1 or 2 reagents (depending on range), 2L each per month

Materials in Contact with Sample
Glass, Silicone, Plexiglass, Stainless Steel AISI 316

Certification (on request):
Meets low voltage and low electromagnetic compatibility directives

Sample Conditioning Requirements
Filtering between 10 and 60 micron, depending on the matrix, needed only to avoid clogging.

Weight
17 kg (37.5 lbs.)

SAMPLE DELIVERY OPERATING CONDITIONS

Temperature Range
5-55º C (41-131º F)

Inlet Sample
100–500 ml/min, atmospheric, flexible tubing O.D. 1/4

Outlet Sample
Atmospheric, waste tubing O.D. 3/8

Turbidity
Not applicable, sample blank correction

Color
Not applicable, sample blank correction

PH
3-12

SIGNAL OUTPUTS

Analog Outputs:
4-20mA (galvanic isolator module available as option) or 0-5V

Serial I/O for Signals:
Serial data output RS232 standard, RS485 available as option

OPERATIONAL CALIBRATION

Frequency/Intervals
Recommended: 7 days

Single/Multi Point
Multi-Point: zero and mid range

Matrix Corrections
Yes, sample blank correction

Manual/Automatic
Both
