AO-SCSJ-V63 Water Purifier Medium Type (Automatic RO/DI Water) (63 L/H)

AO-SCSJ-V63

New

Professional Water purifier produce RO and DI water, widely used in hospital, research lab, industry, university etc.
Automatically power on and power off according the water inflow or water outflow.

Add to wishlist

Type of Instrument Water Purifier
Instrument for: Hospitals, Lab's, Clinics
Function: Water Purifier

- Large LCD display, animation mode, show all the running state and parameters.
- Automatic microcomputer control system, multi-menu operating.
- Alarm function: Water quality, no water, full water, consumables life ending alarm functions. Automatic diagnosis.
- 3-way on-line sensor, detect the quality of feed water, RO water and DI water's quality timely.

Model

AO-SCSJ-V63

Water Output Type

RO and DI water

Water Output Speed

63 L/H

Purifying Procedure

PF+AC+RO+AC+DI+TF

Water Supply Requirement

Tap water: TDS <200ppm, 5 ~ 45°C, 1.0 ~4.0 Kgf/cm2

(if inlet TDS >200 ppm, extra pretreatment filter is recommended)

Purification System

Pretreatment Unit

20" spun fiber filter x 1+20" granular active carbon filter x 1 +20" active carbon block filter x 1

RO unit

400 GPD RO membrane x 1

Subsequent unit

10'' granular active carbon filter x 1 + 12 L mixed bed resin cartridge x 1 + 0.2 μm terminal filer x 1

DI Water Quality

Resistivity

> 10 MΩ.cm

Conductivity

< 0.1 μs/cm

Heavy metal

< 0.1ppb

Particle (> 0.22 μm)

< 1 cfu/ml

Bacteria

< 1/ml

RO Water Quality

TDS (Total dissolved solid) of RO water (ppm)< TDS of inlet water x 5 %

Consumption

120 W

240 W

Power Supply

AC 110/220 V ± 10 %, 50/60 Hz

Standard Configuration

Main body (include1 set cartridge) +2 built-in 15 liters tank

Optional

TDS meter

External Size (W x D x H)

470 x 650 x 1100 mm

Package Size(W x D x H)

650 x 740 x 1250 mm

Gross Weight

70 kg
