H421 Veris AC Transducer adjustable between 1000A & 2400A (4-20mA output)

H421

Veris

New

Volume discounts

Quantity Price
(tax excl.)
You Save
%
1+ 340,00 € 0%
5+ 329,80 € 3%
10+ 319,60 € 6%
15+ 309,40 € 9%

340,00 €

tax excl.

Add to wishlist

H421Veris AC Current Transducer with adjustable input between 1000A & 2400A (4-20mA output)

At AlphaOmega-Electronics you will find the best range of Current Transducerand at the most competitive prices.

"

H421 analog current transducers provide reliable load trending information for large motor loads (1000 to 2400A), with a proportional 4-20mA signal.
This model includes a span potentiometer that allows each sensor to be calibrated for maximum resolution: Zero and span adjustments for field flexibility from 1000 to 2400A.

APPLICATIONS
  • Load trending of large motors

Monitor larger motors and other loads up to 2400A

  • Split-core design for easy installation and fast retrofits
  • Eliminates need for external CTs on large conductors
  • Large openings for heavy conductors
  • Monitor critical motors (compressor, fuel, etc.)

Loop powered 4-20mA output

  • Two-wire design reduces wiring cost
  • Zero and span adjustments for field flexibility
  • 100% solid state...no moving parts to fail
  • 5-year limited warranty

  • Sensor Power 30mA (max)@12-30VDC
  • Insulation Class 600VAC RMS
  • Frequency Range 50/60 Hz
  • Temperature Range -15° to 60°C (5° to 140°F)
  • Humidity Range 10-90% RH, non-condensing
  • Accuracy 2% of FS from 10 to 100% of full scale
  • Response Time 2 sec.
  • Zero Adjustment 3.5 to 4.5mA
  • Agency Approvals UL 508 open device listing
