3044 Analizador de Hidracina View larger

3044 Analizador de Hidracina

3044

Waltron

New

- QUALIDADE DA ÁGUA - Analisador de Hidrazina

El diseño pequeño y compacto hace de la serie 3040 una excelente opción para una variedad de aplicaciones y entornos. Los analizadores colorimétricos de la serie 3040 de Waltron han sido completamente rediseñados para ofrecer configuraciones únicas y simplificadas en comparación con los modelos anteriores.

Range
0 – 100ppb, 0 – 500ppb


Accuracy
+/– 2% of reading


Reproducibility
+/– 2% of reading


Sampling Frequency (Cycle Time)
One reading every 20 mins, adjustable


Required Maintenance
Every 2 weeks replenish reagents; Quarterly replace tubing


Reagent Consumption (approximate)
1 reagent, 4L per month


Sensor Classification
Colorimetric with glass flowcell and LED source


Application
10-45°C analyzer (50-113°F)


Ambient Temperature Range
10-45°C analyzer (50-113°F)


Atmospheric Pressure Range
No Limits


Humidity
Up to 90% not condensable


Unit Dimensions
Height=23.6”(60 cm), Width=15”(38 cm), Depth=8.3”(21 cm)


Positioning and Installation Details
Wall mounting, bench supported, or panel mounting (optional)


Weight
17 kg (37.5 lbs.


Degree of Protection
IP55 (NEMA 4): Wet section, IP65 (NEMA 4x): Electronics


Alarms
2 or 4 configurable alarm relays (Result, loss of sample, fault)


Power Supply (on request)
110-220Vac, 50-60 Hz 80 VA


Certification (on request)
Meets low voltage and low electromagnetic compatibility di

SAMPLE DELIVERY OPERATING CONDITIONS

Temperature Range
5-55º C (41-131º F)


Inlet Sample
100–500 ml/min, atmospheric, flexible tubing O.D. 1/4"(6mm)


Outlet Sample
Atmospheric, waste tubing O.D. 3/8"(9mm)


PH
3-12


Sample Conditioning Requirements
Filtering between 10 and 60 micron, depending on the matrix, needed only to avoid clogging.


Materials in Contact with Sample
Glass, Silicone, Plexiglass, Stainless Steel AISI 316

SIGNAL OUTPUTS

Analog Outputs
4-20mA (galvanic isolator module available as option) or 0-5V)


Serial I/O for Signals

OPERATIONAL CALIBRATION

Single/Multi Point
Multi-Point: zero and mid range


Matrix Corrections
Yes, sample blank correction


Manual/Automatic
Both
