S0121 Thermometer for 2 External Probes With Display (-90°C to + 260°C)

Reference S0121

Condition: New

DISCONTINUED

The Thermometer is designed for record of temperature. Values are stored to a non volatile electronic memory. Data transfer to the personal computer for further analysis is performed via USB, RS232, GSM or Ethernet interface by means of a proper adapter.

Volume discounts

Quantity	Price	You Save %
1+	132,50 €	0%
5+	129,85 €	2%
10+	127,25 €	3.9623%
15+	124,70 €	5.8868%

More info about this product.

Share on Facebook!
Remove this product from my favorite's list.
Add this product to my list of favorites.
Print

Overview
Specifications
Optional Accesories
Compatible Probes

Main thermometer applications:

Transport of food or pharmaceuticals
Food and beverage industry (HACCP)
Pharmaceutical industry
Blood stations, pharmacies
Horticulture and cultivation of plants
HVAC (heating, ventilation, air conditioning, cooling)
Building and energy management
Research and development
Laboratories (GLP)
Warehouses
Technological processes
Museums, archives, galleries
TÜV SÜD certified to conform to EN 12830,
Class 1 and EN 13486, Class 1 for the transport of food

Thermometer advantages:

included traceable calibration certificate from the manufacturer - Comet
fast data transfer to the PC (full memory for approximately 30s)
variability of connection to the computer - USB, RS232, Ethernet, GSM modem
permanent connection to the PC enabled, data is possible to download even during logging
large data memory 32000 values
optional display of minimum and maximum measured values (reset of min/max memory from PC or by magnet)
dual level alarm is enabled for each channel, alarm is indicated by blinking of the LED diode
two alarm modes are enabled: instant or with memory (detected alarm is indicated permanently till alarm memory is cleared from the PC)
robust watertight case
easy installation, locking enabled
low power consumption from battery, battery life up to 7 years
indication of remaining battery life, easy replacement of the battery
standard temperature sensor is Pt1000/3850ppm, switchable to Ni1000/6180ppm external probes at range -50 to +150°C
it is possible to combine temperature measurement with logging of contact state (e.g. door contact)
logging start/stop is enabled in several ways: at certain time and date programmed from computer, by delivered magnet
also special logging mode is enabled, when logging runs only, if some of measured values are out of adjusted alarm limits
each logger is possible to describe with text of maximum 32 characters
each channel is possible to describe with text of maximum 16 characters
password protection is enabled to prevent unauthorized manipulation with logger

Included in delivery:

Data logger including the battery
Traceable calibration certificate with declared metrological traceability of etalons is based on requirements of EN ISO/IEC 17025 standard.
Quick start manual
Free basic Windows software is ready to download at folder

Technical parameters	Value
Measured Value	Temperature
Construction Type	For Two External Temperature Probe Pt1000
Temperature Measuring Range	-90 to +260°C
Two-State Input	No
Lcd Display	Yes
Built-In Printer	No
Operating temperature range	-30 to +70°C
Accuracy of temperature input without probe	±0.2°C from -50 do +100°C ±0.2% from reading from +100 to +260°C ±0.4% from reading from –90 to –50°C
Resolution of the reading	0.1°C
Real time clock	year, leap year, month, day, hour, minute, second
Data logging interval	adjustable from 10s to 24h
Display and alarm refresh	each 10 s
Total memory capacity	32000 temperature values in noncyclic logging mode
Data logging mode	noncyclic - data logging stops after filling the memory cyclic - after filling memory oldest data is overwritten by new
Dimensions	93x64x29mm
Power	Lithium battery 3,6V, size AA
Typical battery life	6 years
Battery life in continuous on-line mode with interval 1 minute	reduced to 70% of the above life
Battery life in continuous on-line mode with interval 10 second	1 year
IP protection	IP67 - protected against influence of temporary immersion into water
Weight including battery	115g
Warranty	2 years

GSM communication

KIT - GSM/GPRS modem LP040 with accessories for Sxxxx, Rxxxx loggers code: KIT-GSM-L	COM adapter with protection IP65 code: LP012	GSM/GPRS MODEM for data loggers of Sxxxx, Rxxxx, Gxxxx families code: LP040
antenna for GSM modem FASTRACK code: MP009/1	AC/DC adapter 230Vac to 24Vdc/1A, switch-mode code: A1940	Communication cable for GSM modem code: QMS2901
Transducer USB/RS232 complete code: MP006	Self Adhesive Dual Lock code: MD036	Wall holder for GPRS modem code: MP036
DIN Rail 35mm holder for GPRS modem code: MP037	One time fee for using M2M server - applied for each data logger with modem code: SLU302

Pt1000TG8/E, temperature probe, cable 1 m/ -80 to +200°C. code: SN104E	Pt1000TG8/E, temperature probe, cable 2 m/ -80 to +200°C. code: SN105E	Pt1000TG8/E, temperature probe, cable 5 m/ -80 to +200°C. code: SN108E
Pt1000TG8/E, temperature probe, cable 10 m/ -80 to +200°C. code: SN113E	Pt1000TG7/E, temperature probe, cable 1 m/ -30 to +200°C code: SN164E	Pt1000TG7/E, temperature probe, cable 2 m/ -30 to +200°C code: SN165E
Pt1000TG7/E, temperature probe, cable 5 m/ -30 to +200°C code: SN166E	Pt1000TG7/E, temperature probe, cable 10 m/ -30 to +200°C code: SN167E	Pt1000TG68/E, temperature probe, cable 2 m/ -30 to +150°C. code: SN232E
Pt1000TG68/E, temperature probe, cable 5 m/ -30 to +150°C. code: SN233E	Pt1000TG68/E, temperature probe, cable 10 m/ -30 to +150°C. code: SN234E	2301-220/E, temperature probe, cable 1 m/ -30 to +220°C code: SN168E
2021-150/E, temperature probe, cable 1 m/ 30 to +150°C code: SN169E	PTS350A-2/0, temperature probe, cable 2 m/ -30 to +130°C code: SN170E	2034-220/E, temperature probe, cable 1 m/ -50 to +220°C code: SN175E
2061-200/E, temperature probe, cable 1 m/ -30 to +200°C code: SN178E	2061-200/E, temperature probe, cable 2 m/ -30 to +200°C code: SN179E	2061-200/E, temperature probe, cable 5 m/ -30 to +200°C code: SN180E
2061-200/E, temperature probe, cable 10 m/ -30 to +200°C code: SN181E	PTS350A-5/E, temperature probe, cable 5 m/ -30 to +130°C code: SN182E	PTS350A-10/E, temperature probe, cable 10 m/ -30 to +130°C code: SN183E
Pt1000TGL40/E, temperature probe, cable 1 m/ -30 to +80°C. code: SN185E	Pt1000TGL40/E, temperature probe, cable 2 m/ -30 to +80°C. code: SN186E	Pt1000TGL40/E, temperature probe, cable 5 m/ -30 to +80°C. code: SN187E
Pt1000TGL40/E, temperature probe, cable 10 m/ -30 to +80°C. code: SN188E	Pt1000TR160/E, temperature probe, cable 1 m/ -30 to +80°C. code: SN199E	Pt1000TR160/E, temperature probe, cable 2 m/ -30 to +80°C. code: SN200E
Pt1000TR160/E, temperature probe, cable 5 m/ -30 to +80°C. code: SN201E	Pt1000TR160/E, temperature probe, cable 10 m/ -30 to +80°C. code: SN202E	Pt1000TR160/E, temperature probe, cable 15 m/ -30 to +80°C. code: SN203E
Pt1000TR160/E, temperature probe, cable 20 m/ -30 to +80°C. code: SN204E	PTS380K/E temperature sensor with a stainless steel connection head and connector/ -30 to +200°C code: SN205E	2091-200/E, Stick-in probe, cable 1 m code: SN210E -30 to +200°C
2091-200/E, Stick-in probe, cable 2 m code: SN211E -30 to +200°C	2091-200/E, Stick-in probe, cable 5 m code: SN212E -30 to +200°C	2091-200/E, Stick-in probe, cable 10 m/ -30 to +200°C code: SN213E
200-80/E, air temperature probe code: SN171 -30 to +80°C
